Outdoor Wireless Parking Guidance

Lora Wireless Gateway

-20℃ ~ +65℃
Product description: SintronicParking Lora Wireless Gateway collects sensor data for parking guidance system, long‑range wireless transmission, stable connection for parking lot projects.
INQUIRY

Item	Specification
Product Name	Lora Wireless Gateway
Communication Standard	LoRa / LoRaWAN Protocol
Working Frequency	EU868 / US915 / AS923 Multi‑band Optional
LoRa Channels	8‑channels for sensor receiving
Max Transmit Power	27dBm
Receive Sensitivity	-140dBm
Wireless Distance	Up to 3‑5km open area, 500‑1000m indoor parking lot
Max Access Nodes	Support up to 500 parking sensors
Wired Interface	10/100Mbps RJ45 Ethernet, PoE 802.3af Power Supply
Backhaul	Ethernet, Optional 4G/LTE module
Application	Parking Guidance System, collect ground sensor data
Working Temperature	-20℃ ~ +65℃
Protection Grade	IP30 Indoor / IP68 Outdoor option
Power Input	DC12V / PoE
Installation	Wall‑mount, Ceiling‑mount
